200A 3P 25KA Schneider Circuit Breaker

Rs. 81,260.00

Negotiable

Store | VERIFIED

WEDABIMA HARDWARE Electrical Products

Call

0774953653

info@wedabimahardware.lk

Location

Sausiri Complex , High Level Road , Nugegoda

BUY NOW

Description

200A 3P 25KA Schneider Circuit Breaker

Brand - Schneider

Model - LV525302

Range of Product - EasyPact CVS100...250

Product Name - EasyPact CVS

Device short name - CVS250B

Product or Component Type - Circuit Breaker

Device Application - Distribution

Poles Description - 3P

Protected Poles Description - 3D

Earth leakage protection (Vigi add on) Without

[In] Rated current 200A at 40 °C

Network Type - AC

Utilisation Category - Category A

[Icu] Breaking capacity - 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2

Trip unit name - TM-D
Trip unit technology - Thermal-magnetic
Trip unit rating - 200A at 40 °C
Protection type - Short-circuit protection (magnetic)
Overload protection (thermal)

Complementary
[Uimp] rated impulse withstand voltage - 8 kV conforming to EN/IEC 60947-2
Network frequency - 50/60 Hz
Breaking capacity code - B
[Ics] rated service breaking capacity - 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2
40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2

Mechanical durability - 20000 cycles
Electrical durability - 10000 cycles 415 V In conforming to IEC 60947-2
Control type - Toggle
Thermal protection adjustment range - 140..…200 A
Long time pick-up adjustment type Ir - Adjustable

Long time pick-up adjustment range - 0.7...1 x In
Long time delay adjustment type - Fixed
Instantaneous pick-up adjustment type Ii - Fixed
Instantaneous pick-up adjustment range - 2000 A
Contact position indicator - Yes
mounting support - Backplate
mounting mode - Fixed
Upside connection - Front
downside connection - Front
Connections - terminals Screw connection
Connection pitch - 35 mm
Compatibility code - CVS250
Width - 105 mm
Depth - 86 mm
Height - 161 mm
net weight - 1.7 kg

Environment
Standards - IEC 60947-2 /EN 60947-2
product certifications - GOST IEC
Electrical shock protection class - Class II
Pollution degree - 3 conforming to IEC 60664-1
IP degree of protection - IP40
ambient air temperature for operation -25…70 °C
ambient air temperature for storage -50…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 11.000 cm
Package 1 Width - 14.000 cm
Package 1 Length - 19.000 cm
Package 1 Weight - 1.939kg

Unit Type of Package 2 - S03
Number of Units in Package 2 - 8
Package 2 Height - 30.000 cm
Package 2 Width - 30.000 cm
Package 2 Length - 40.000 cm
Package 2 Weight - 15.899 kg

Advertisers are responsible for ensuring that advertising content, text, images, graphics ("Content") uploaded for inclusion on wedabima.com complies with all applicable laws. wedabima.com & D Factor Group assumes no responsibility for any illegality or any inaccuracy of the Content. wedabima.com and D Factor Group make no warranty or representation for any products, services, deals and transactions between the user and the advertisers. Users strictly at their own risk. The advertisers and user guarantees that his or her Content do not violate any copyright, intellectual property rights or other rights of any person or entity, and agrees to release wedabima.com and D Factor Group from all obligations, liabilities and claims arising in connection with the use of (or the inability to use) the service. Advertisers agree that their Content can may be presented through wedabima.com's partner sites under the same terms and conditions as on wedabima.com

wedabima.com and D Factor Group make no warranty or representation for any products, services, deals and transactions between the user and the advertisers. Users strictly at their own risk.

Related Items

63A 3P - 25KA Schneider Circuit Breaker

Rs. 37,940.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

63A 3P - 25KA Schneider Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - LV510305 Range of Product - EasyPact Product Name - EasyPact CVS , etc... Find best deals from වැඩබිම

0774953653

3 Pole - 06A Schneider Miniature Circuit Breaker

Rs. 8,130.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

3 Pole - 06A Schneider Miniature Circuit Breaker price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - A9N3P06C Device application - Distribution Range of, etc... Find best deals from වැඩබිම

0774953653

2 Pole 40A Schneider Switch Disconnector

Rs. 3,800.00

BUY NOW VISIT STORE | WEDABIMA HARDWARE Electrical Products

2 Pole 40A Schneider Switch Disconnector price in Sri Lanka. Best deals from වැඩබිම.com for Hardware items in Sri Lanka. Brand - Schneider Model - EZ9S16240 Range - Easy9 Product or Component Type - Switch , etc... Find best deals from වැඩබිම

0774953653

23A - 32A Overload Relay - D Range
