250A 3P 25KA Schneider Circuit Breaker

Rs. 55,970.00

Negotiable

Store | VERIFIED

WEDABIMA HARDWARE Electrical Products

Call

0774953653

info@wedabimahardware.lk

Location

Sausiri Complex , High Level Road , Nugegoda

BUY NOW

Description

250A 3P 25KA Schneider Circuit Breaker

Brand - Schneider

Model - EZC250N3250

Range of Product - EasyPact

Product or Component Type - Circuit Breaker

Device short name - Easypact EZC100N

Circuit Breaker Name - Easypact - EZC100N

Device Application - Distribution

Poles Description - 3P

Protected Poles Description - 3T

Network Type - AC/DC

Network Frequency - 50/60Hz

[In] Rated Current - 250A at 40 °C

[Ui] Rated insulation Voltage - 690 V AC 50/60 Hz conforming to IEC 60947-2

[Uimp] Rated Impulse withstand Voltage - 6 kV conforming to IEC 60947-2

[Ue] Rated operational voltage - 550 V AC 50/60 Hz conforming to IEC 60947-2
250 V DC conforming to IEC 60947-2

Breaking Capacity code - N

Breaking capacity - 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2
50 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2
20 kA Icu at 125 V DC 1P conforming to IEC 60947-2
20 kA Icu at 250 V DC 2P conforming to IEC 60947-2
25 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2
25 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2
8 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2

[Ics] rated service breaking capacity - 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
25 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2
10 kA at 125 V DC conforming to IEC 60947-2
10 kA at 250 V DC conforming to IEC 60947-2
25 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2
4 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2
12.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2
12.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2

Suitability for isolation - Yes conforming to IEC 60947-2
Utilisation category - Category A
Trip unit name - TM-D
Trip unit technology - Thermal-magnetic
Trip unit rating - 250 A at 50 °C
Protection type - Overload protection
Short-circuit protection

Pollution Degree - 3 conforming to IEC 60664-1
3 conforming to IEC 947-1

Complementary
Control type - Toggle
mounting mode - Fixed
mounting support - Backplate
Upside connection - Front
downside connection - Front
Mechanical durability - 10000 cycles
Electrical durability Category - A: 5000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2
Connection pitch - 35 mm
Local signalling - Positive contact indication
Neutral protection setting - Without protection
Earth-leakage protection - Without
Height - 165 mm
Width - 105 mm
Depth - 60 mm

Environment
Standards - EN/IEC 60947-1/JIS C8201-2-2 /GB/T 14048.2
EN/IEC 60947-2
IP degree of protection - IP20 conforming to IEC 60529
IK degree of protection - IK07 conforming to IEC 62262

ambient air temperature for operation -25…70 °C
ambient air temperature for storage - 35…85 °C

Packing Units
Unit Type of Package 1 - PCE
Number of Units in Package 1 - 1
Package 1 Height - 12.0 cm
Package 1 Width - 11.0 cm
Package 1 Length - 18.2 cm
Package 1 Weight - 1.57 Kg

Unit Type of Package 2 - S03
Number of Units in Package 2 - 8
Package 2 Height - 30 cm
Package 2 Width - 30 cm
Package 2 Length - 40 cm
Package 2 Weight - 14.9 kg
Unit Type of Package 3 - P12

Number of Units in Package 3 - 64
Package 3 Height - 50 cm
Package 3 Width - 80cm
Package 3 Length - 120 cm
Package 3 Weight - 124.7 kg

18 Months Company Warranty
